Yamaha Trike Kits

---

For Roadliner & Stratoliner Models– 2006 to 2012

 For Royal Star Venture & Tour Deluxe Models – 1999 and up

 Need help starting your incredible journey? Get up to $25,000 in select products and services.
Click the pic to take the first step.

Ask about our convenient pick up and delivery program and leave the heavy lifting to us!

Click on CONTACT OPTIONS to ;learn more.

Make your machine unique with custom handlebars, light kits and more. Click the pic to see more.

 Introducing the industry's first trike kit for the Yamaha Roadliner and Stratoliner models.

Designed to match the motorcycle, the trike body incorporates the chrome accents from the fuel tank and keeps the spoke wheel look and teardrop style LED taillights of the motorcycle.

PAINT CARE

The care of the paint is critical for the first 90 days of the trike body. Do not cover the trike body and / or wax the trike body for the first 90 days. The paint is however, suitable for pin striping and / or painting of murals at the time the trike body leaves the factory.

•  Curb weight - 1180
• Tke kit weight - 606 lbs
• Wheel base with Power Trak -  79.3 in
• Overall Length with PowerTrak - 117 in
• Track - 47.875 in
• Overall Width - 61 in
• Ground Clearance - 4.42 in
• Trailer Hitch Ball Height (1-7/8 ball) - 13 in*
• Trunk Storage Capacity - 6.5 cu ft
•  Tires: - 205 / 60R15 All Season Radial
• Recommended tire pressure
  • Rear tires – 28 psi
  • Front tire – 36 psi
• Wheel: - 15 x 6.5 with 5 on 100mm bolt pattern. Silver Split 5-spoke  or optional chrome Split 5-spoke & chrome 9-spoke wheel to match  front cast wheel
• Lug Nuts: - m12 x 1.5 ET conical lug nuts torque to 65 ft/lbs

•  Trailer wiring harness: Equipped with the female connector for the  Escapade line of trailers. Male connector may be purchased separately  through California Sidecar Parts & Service Department.
• Emergency release cable: Located just above the battery box on the  left side of the trike, this cable releases the trike body trunk door in  case of primary latch malfunction.

•  Performance designed independent suspension with vertically stabilized opposing Rocker Mono Shock
• Shock Spring: QA1 300 lb. linear wound racing spring designed to accommodate up to 650 lbs plus optional preloader.
• Twin reduction jackshaft belt drive with 50mm Gates performance belt
• Rubber isolated drive sprocket for a smooth drive

•  Standard: Alloy calipers with 11.5” purpose designed rotors
• Performance Brake (optional upgrade): custom designed nickel plated  drilled rotors with custom twin piston billet calipers. Calipers are  brushed aluminum and red anodized and then engraved with “California  Sidecar”.

 Need help starting your incredible journey? Get up to $25,000 in select products and services.
Click the pic to take the first step.

Hannigan engineering at its finest; all covered by the great Hannigan warranty

• Length w/Steer-Lite Kit Installed - 112"
• Wheelbase w/Steer-Lite Kit Installed - 74"
• Width - 61.5"
• Track Width - 51"
• Trunk Capacity -  6.0 cu tf.
• Rear Tires-All Season Radials - 195/55 R16
• Rear Wheels-High Polished Aluminum(standard) - 16x7, 4x100 bolt pat, 39mm offset

 Make your machine unique with custom options from Pair-a-Dice Trikes. Click the pic to see more.

For model years 2007 and up

Need help starting your incredible journey? Get up to $25,000 in select products and services.

Click the pic to take the first step.

 For 1500 Classic – 2001 to 2008

For 1500 Nomad – 2001 to 2004
For 1600 Classic – 2003 to 2008;

For 1600 Nomad – 2005 to 2009.

For 2000 Vulcan Models

Make your machine unique with custom options from Pair-a-Dice Trikes. Click the pic to see more.

CSC Introduces its latest trike for the Kawasaki Vulcan 900 bike. This trike will meet the demands for those looking for a lower entry price in purchasing a trike. This trike also provides a less intimidating trike without giving up exceptional handling, style and performance. The INDY trike can still ride with the Big Boys and still provide the comfort and handling you would expect from the bigger trikes. The INDY is the only Kawasaki 900 trike in the market that offers an optional electric reverse and an optional tour box for the extra storage benefits.

The INDY creates a trike with great value without compromising style and performance. See below for more information on the INDY. Fits the Kawasaki Vulcan 900 from 2007 to date

•  Total weight - 1132 lb (468 kg)
• Wheel base w/o PowerTrak - 74.3 in (188.7 cm)
• Wheel base with Power Trak - 78.7 in (199.9 cm)
• Overall Length with PowerTrak & Light bar - 113 in (287.0 cm)
• Overall Length w/o PowerTrak or Light bar - 107 in (271.8 cm)
• Track:47.9 in (121.7 cm)
• PowerTrak - 5.6º
• Overall Width with chrome trim - 60.2 in (152.9 cm)
• Ground Clearance - 4.5 in (11.4 cm)
• Trailer Hitch Ball Height (1-7/8  ball):- 13 in*
• Trunk Storage Capacity- :6.5 cu ft (184.1 litre)
• Turning Radius with PowerTrak - 11 ft (335.3 cm)

  Let  Pair-a-Dice Trikes take care of pick up and delivery of your motorsport  machine and save time, trouble and headaches. Click the pic to start the fun.  .

For 1500 Classic – 2001 to 2008; For 1500 Nomad – 2001 to 2004;

For 1600 Classic – 2003 to 2008; For 1600 Nomad – 2005 to 2009.

• Length w/Steer-Lite Kit Installed - 113"
• Wheelbase w/Steer-Lite Kit Installed - 74"
• Width - 59"
• Track Width - 49"
• Trunk Capacity - 6.0 cu ft.
• Rear Tires - All Season Radials - 195/55 R16
• Rear Wheels - High Polished Aluminum(standard) - 16x7, 4x100 bolt pat, 39mm offset

 Need help starting your incredible journey? Get up to $25,000 in select products and services.
Click the pic to take the first step.

Make your bike unique with customized accessories from Pair-a-Dice Trikes including specialty handlebars, LED light kits and more. Click the pic for more details.

•  Length w/Steer-Lite Kit Installed - 108.5"
• Wheelbase w/Steer-Lite Kit Installed - 75"
• Overall Width - 60.5"
• Track Width - 50"
• Trunk Capacity - 3.0 cu ft. approx
• Rear Tires - All Season Radials -  215/40R17
• Rear Wheels - 7 spoke Brushed Aluminum 17x7, 4x100 bolt pat, 39mm offset
• Rear Wheel Upgrade -7 spoke Chromed 17x7, 4x100 bolt pat, 39mm offset

  Let  Pair-a-Dice Trikes take care of pick up and delivery of your motorsport  machine and save time, trouble and headaches. Click the pic to start the fun.
