I For VTX1300 R & S Models – 2005 and up
Every HSC1300 Roadsmith Trike is built with the attention and craftsmanship needed to be a true extension of the Honda™ motorcycle itself. Take a closer look and you will see what we mean.
Have Fun, Worry-Free
Save time and hassle with our convenient pick up and delivery option
Wheelbase - 76" with steeingr kit
Overall length - 111" with steering kit
Overall width - 56" at the body
Weight - 1050 lbs wet
Storage - 29.5" wide x 14.5" high opening x 15" deep = 3.7 CF
Suspension - Lateral trailing arm Independent
Rear Suspension
Stabilizer bar - 5/8" bar to control body roll/or 3/4" Option
Tires, rear - 215/55-16 radial
Rims, rear - 16x7 alloy 5x4 1/2 35mm offset
Final drive ratio - 3.07:1
Brakes, rear - Dual piston calipers
Shocks - Adjustable coil over
Body material - Polyester resin fiberglass
Drive system - 2" diameter shaft w/ sealed u-joints
Need help starting your incredible journey? Get up to $25,000 in financing for select products and services.
Make your machine unique with custom accessories from Pair-a-Dice Trikes. Click the pick to see the selection.
Check out our FAQ section for answers to questions which may help you make up your mind.
VTX1800 R & S Models – 2005 and up
Every HCS1800 Roadsmith Trike is built with the attention and craftsmanship needed to be a true extension of the Honda™ motorcycle itself. Take a closer look and you will see what we mean.
Have Fun, Worry-Free
For VTX1800 R & S Models – 2005 and up
Every HCS 'R' 1800 Roadsmith Trike is built with the attention and
craftsmanship needed to be a true extension of the Honda™ motorcycle itself. Take a closer look and you will see what we mean.
Designed for the VTX1800R and S model. Have a fun, on a worry-free ride.
HSCR1800
Wheelbase - 79" with steeingr kit
Overall length - 111" with steering kit
Overall width - 56" at the body
Weight - 1070 lbs wet
Storage - 27" wide x 14" high opening x 15" deep
Suspension - Lateral trailing arm Independent
Rear Suspension
Stabilizer bar - 5/8" bar to control body roll
Tires, rear - 215/55-16 radial
Rims, rear - 16x7 alloy 5x4 1/2 35mm offset
Brakes, rear - Dual piston calipers
Shocks - Adjustable coil over
Body material - Polyester resin fiberglass
Drive system - 2" diameter shaft w/ sealed u-joints
Gel-Coat (in Base Price)
Vehicles are no longer being painted by the manufacture with a fixed color. Current paints contain variants that can occur in the mixing, application, and human process, that contribute to the difficulty of matching colors. Due to the complexity of the colors being used by the manufacturers, color matching paint of an existing product in some cases can be extremely difficult. In addition, Age of vehicle, and fading throughout the years, add to the difficulty of matching paint.
Champion Motorcycle Accessories International, Inc. takes extra steps to deliver a professional paint job that will match the existing paint however, in all of our diligence; we cannot and will not guarantee an exact color match.
