Harley Touring Trike Kits 780-789-1933

CSC Daytona

CSC Daytona Trike Kit from Pair-a-Dice Trikes

 For Touring Models 1999 and up

Hannigan Transformer

Hannigan Transformer Trike Kit from Pair-a-Dice Trikes

For Touring Models 1999 and up

Hannigan FLH

Hannigan FLH Trike Kit available from Pair-a-Dice Trikes

 For Touring Models 1999 and up

Roadsmith HDT

Roadsmith HDT Trike Kit available from Pair-a-Dice Trikes

For Touring Models 1996 and up

Roadsmith HDTR

Roadsmith HDT-R Trike Kit available from Pair-a-Dice Trikes

 For Touring Models 1996 and up

Roadsmith HDTV

Roadsmith HDT-V Trike Kit available from Pair-a-Dice Trikes

 For Touring Models 1996 and up

Champion FL

Champion FL trike kit sold by Pair-a-Dice Trikes

 For Touring Models 1987 and up

Champion FL IS

Champion FL IS Trike Kit from Pair-a-Dice Trikes

 For Touring Models 1987 and up

Take a load off your mind

A sign advising people of the pick up and delivery option offered by Pair-a-Dice Trikes.

  Let  Pair-a-Dice Trikes take care of pick up and delivery of your motorsport  machine and save time, trouble and headaches. Click the pic to start the fun.

CSC Daytona HD Touring Trike Kits - 1999 & up

Style Meets Performance

Harley Davidson owners demand the ultimate in style and performance  and accept nothing less in the equipment they ride. California Sidecar  recognized that when we designed the CSC Daytona trike conversion kit.  The suspension is the result of superb performance engineering and  innovation. A light-weight aircraft grade aluminum suspension works with  our exclusive nitrogen charged shock and Eibach springto deliver  ultimate handling and cornering ability. Whether dodging potholes on the  Interstates or sweeping through tight 2-laned turns, the Daytona  handles better than any other trike on the planet.


Great Drivetrain


The drivetrain is equally well engineered as-purpose built sprockets  retain the stock gear ratio. The CSC exclusive belts are a proprietary  material and design, manufactured by Gates, the industry leader in belt  technology and production. Four piston disc brake calipers are standard  equipment, providing unmatched stopping power under all conditions.  Check out the optional Performance Brake Upgrade, a drilled rotor with  nickel plating and a super-slick aluminum caliper.A meticulously styled  body with our custom LED taillights will turn heads wherever you may  roam. And with our internally mounted Space Saver hinge design and over 6 cubic feet of trunk storage capacity, there’s not much you’ll ever have to leave behind.


 (*300 lb coil spring weight; higher and lower spring weights available)

 LINK TO BROCHURE PDF


CSC Daytona HD Trike Kit Details

That’s about the size of it

Specifications of a CSC Daytona trike

  •  Rated Load Capacity 650 lbs*
  • Wheel 16 X 7 in, 5 on 100 mm bolt pattern + 35mm offset
  • Wheel Base 72.5 in (184.2 cm)
  • Wheel Base with Power Trak 73.5 in (186.7 cm)
  • Overall Length 102.5 in (260.4 cm)
  • Overall Length with Power Trak & Lightbar 111.5 in (283.21 cm)
  •  Track 47.875 in (121.6 cm)
  • Trike Width with Lightbar 61 in (154.94 cm)
  • Ground Clearance 5 in (12.7 cm)
  • Trunk Storage Capacity 6.3 cu. Ft.

Circles of Life

CSC Daytona Trike wheels and tires

 16x7, 5x100mm bolt pattern, American Racing split 5-spoke w/ silver powder coat finish

  • 205/55R16 All Season radial tire
  • Many Wheel Upgrades available
  • Superior Styling & Finish

In typical California Sidecar Trike fashion, we’ve crafted a body  with an aggressive, sleek style that perfectly complements the style of  the Harley Davidson. The body is equipped with custom LED taillights  that incorporate the brake, running and turn signal lights into one cool  chrome unit. Also standard are the rear chrome trim accent strips and 4  LED auxiliary running lights to increase visibility. Each painted body  comes with the finest finish in the business. Our in-house fiberglass  and paint departments insure the highest degree of quality control and  the color match capability is unsurpassed. Bodies are wet sanded and  then polished in a two-step process to achieve the amazing paint finish  that we demand.Having a big sale, on-site celebrity, or other event? Be sure to announce it so everybody knows and gets excited about it.

Suspension System

CSC Dayton trike suspension

 Hands down, the most innovative suspension engineering design on the  market! Based on Indy car technology, the DAYTONA features a vertically  stabilized opposing rocker mono shock independent suspension, plus:

  • Light weight & strong cast and forged aluminum structural components
  • Purpose designed JRI nitrogen-charged shock
  • Eibach 300Lb spring designed to accommodate a loaded weight of up to 650lbs
  • An optional CSC hydraulic preloader to accommodate varying loads.
  • Maintenance and adjustment free components

Disc Brake System

CSC Daytona trike brake system

 Outstanding braking performance is supplied by CSC’s standard 4 piston  calipers, 11.5” rotors, and braided stainless steel brake lines  throughout. To add even more style and performance, check out the  performance brake upgrade.

The industry's best warranty


 5 Year/UNLIMITED MILE Warranty

Ride with confidence!

CSC offers the best warranty in the trike world.

Bolt-On Installation

CSC Daytona trike bolt-on installation system

  All California Sidecar Trike conversions are completely bolt-on kits. No welding required. Every kit we sell comes with mounting hardware, detailed photo instructions, wiring harnesses, and technical support.

Hannigan Transformer Trike Kits 780-789-1933

Hannigan FLH Transformer Trikes For Touring Models 1999 and up



  • Length w/Steer-Lite Kit Installed 111"
  • Wheelbase w/Steer-Lite Kit Installed 70.5"
  • Width 59"
  • Track Width 49"
  • Trunk Capacity 9 cu ft
  • Rear Tires-All Season Radials 205/45 R17
  • Standard Rear Wheels-Silver Machined Aluminum 16" 16x7, 4x100 bolt pat, 45mm offset
  • Upgrade Rear Wheels-17" Premium Chrome Split-Spoke Design 17x7, 4x100 bolt pat, 45mm offset
  • Trike Conversion Adds Approximately 300 lbs to stock FLH

LINK TO BROCHURE PDF


Hannigan FLH Trike Kits for Harley-Davidson

Hannigan FLH: For Touring Models – 1999 and up


  • Length w/Steer-Lite Kit Installed 102"
  • Wheelbase w/Steer-Lite Kit Installed 67"
  • Width 58"
  • Track Width 49"
  • Trunk Capacity 5 cu ft
  • Rear Tires-All Season Radials 205/55 R16
  • Standard Rear Wheels-High Polished Aluminum 16" 16x7, 4x100 bolt pat, 39mm offset
  • Upgrade Rear Wheels-Premium Chrome Split-Spoke Hays Design 16x7, 4x100 bolt pat, 39mm offset
  •  LINK TO BROCHURE PDF


Roadsmith HDT/HDTR Trike Kits 780-789-1993

For Touring Models 1996 and up

Roadsmith logo

Hit the road with the HDT and HDTR Roadsmith trike conversions, and experience the trike-riding difference. With a longer wheelbase, generous additional storage, independent suspension, disc brakes, optional electric reverse, and Roadsmith steering kit, you may never want to return home!

That’s about the size of it

Roadsmith HDT/HDTR trike kit specifications

  •  Wheelbase  - 72"
  • Overall length - 108"
  • Overall width  -  56" at the body 58" wide with Running Boards
  • Weight - 1150 lbs soaking wet
  • Storage - 27" wide x 14" high opening x 15" deep
  • Suspension  - Lateral trailing arm Independent Rear Suspension
  • Stabilizer bar  - 5/8" bar to control body roll
  • Tires, rear  - 215/55-16 radial
  • Rims, rear  - 16x7 alloy 5X4 1/2 bolt pattern with 35mm offset
  • Final drive ratio  - Same as bike
  • Brakes, rear - Dual 35mm piston calipers
  • Shocks - Adjustable coil over
  • Body material  - Polyester resin fiberglass
  • Drive system -170 tooth Gates PolyChain GT2 Carbon Fiber 1 1/8" wide

All the Bells and Whistles

Roadsmith HDT & HDTR features

  •  Independent rear suspension
  • True track stabilizer bar
  • Longer wheelbase
  • Belt Driven Differential
  • Gates Polychain HD belt
  • Disc brakes
  • Alloy wheels
  • Storage Compartment
  • Factory styled body
  • Trailer hitch receiver
  • Steering kit
  • 3 year 1,000,000 mile warranty

Roadsmith HDTV Trikes at Pair-A-Dice Trikes

For Touring Models – 1996 and up

Roadsmith logo

 Simply the Best Harley Davidson™ Trike Conversion Kit Available.  Hit the road with the all new Roadsmith conversion kit by The Trike Shop  and experience the trike-riding difference. With a longer wheelbase, generous additional storage, independent suspension, disc brakes,  optional electric reverse, and Roadsmith steering kit, you may never want to return home!

That’s about the size of it


  •  Wheelbase - 78"
  • Overall length - 116"
  • Overall width - 56" at the body
  • Weight-  1150 lbs wet
  • Storage - 27" wide x 14" high opening x 15" deep
  • Suspension - Lateral trailing arm Independent Rear Suspension
  • Suspension adjustment - manual pre-load
  • Stabilizer bar 5/8" bar to control body roll
  • Tires, rear - 215/65-16 radia
  • Rims, rear - 16x7 alloy 5x4 1/2" 35mm offset
  • Final drive ratio - 70 tooth sprocket
  • Brakes, rear-  dual piston calipers
  • Shocks - adjustable coil over
  • Body material - polyester resin fiberglass
  • Drive system - 1 1/8" Gates Polychain 170 teeth

All the Bells and Whistles

Roadsmith HDTV Trike kit features

  •  Independent rear suspension
  • True track stabilizer bar
  • Longer wheelbase
  • Belt driven differential
  • Gates Polychain HD belt
  • Disc brakes
  • Alloy wheels
  • Storage Compartment
  • Factory styled body
  • Trailer hitch
  • Steering kit
  • 3 year 1,000,000 mile warranty on the entire trike kit

Champion FL & FL-IS from Pair-a-Dice Trikes

That’s about the size of it

Champion FL and FL-IS specifications

  •  Overall Width.- 54.5"
  • Overall Length - 97.25"
  • Overall Length (w/ EZ-Steer) - 99.75"
  • Wheelbase - 63"
  • Wheelbase (w/ EZ-Steer) - 65.5"
  • Load Capacity - 500 pounds
  • Tire Size - 205/70/R15
  • Brakes - High performance disc
  • Trunk capacity - 5.75 cubic feet
  • Suspension - Double-A-Arm Independent Suspension w/high pressure gas shock absorbers

All the Bells and Whistles

Champion FL and FL-IS features

  •  Gel-Coat (in Base Price)
  • High-performance, independent front and rear disc brake systems - Increased safety when braking in turns
  • Champion-designed "Easy-Install" rear-end - A custom-made differential, designed to fit the OEM's drive sprocket.
  • Powder-coated structural components - Improved durability, longer lasting coating system
  • Reinforced fiberglass body construction - Rugged, durable product that will last longer
  • Extra-large trunk plus over-wheel storage - Increased capacity: two full-face helmets and more
  • OEM tail and signal lights - Preserves classic FLH styling features.

About Paint Matching

A spary painter with paint matching information

Vehicles are no longer being painted by the manufacture with a fixed  color. Current paints contain variants that can occur in the mixing,  application, and human process, that contribute to the difficulty of  matching colors. Due to the complexity of the colors being used by the  manufacturers, color matching paint of an existing product in some cases  can be extremely difficult. In addition, Age of vehicle, and fading  throughout the years, add to the difficulty of matching paint.

Champion Motorcycle Accessories International, Inc. takes extra steps  to deliver a professional paint job that will match the existing paint  however, in all of our diligence; we cannot and will not guarantee an  exact color match.

Kit includes all this

The contents of a Champion FL and FL-IS trike kit

  •  Instruction manual
  • All electrical components factory installed
  • All mounting hardware
  • Complete detailed instructions
  • High performance disc brakes
  • Wheels (aluminum alloy) and mounted, balanced tires (205/70/R15)

Up to $25,000

A sign advising Pair-a-Dice Trikes offers financing options

 Don't let a few dollars stand in the way of your dreams. Click the pic to get your ride rolling

The Champion Warranty

Champion FL and FL-IS warranty

3 Year/UNLIMITED MILE WARRANTY

Click the pic to learn more details
